press.svg · 225 lines
<svg xmlns="http://www.w3.org/2000/svg" width="960" height="1330" viewBox="0 0 960 1330">
<defs>
<!-- cylindrical chrome shading (horizontal bands) -->
<linearGradient id="chrome" x1="0" y1="0" x2="1" y2="0">
<stop offset="0" stop-color="#7f888f"/>
<stop offset="0.12" stop-color="#dfe6ea"/>
<stop offset="0.28" stop-color="#ffffff"/>
<stop offset="0.46" stop-color="#c2ccd3"/>
<stop offset="0.68" stop-color="#8b949c"/>
<stop offset="0.85" stop-color="#d7dee3"/>
<stop offset="1" stop-color="#6f787f"/>
</linearGradient>
<linearGradient id="chromeTop" x1="0" y1="0" x2="1" y2="0">
<stop offset="0" stop-color="#aab3ba"/>
<stop offset="0.18" stop-color="#eef3f6"/>
<stop offset="0.4" stop-color="#ffffff"/>
<stop offset="0.62" stop-color="#cfd7dc"/>
<stop offset="0.85" stop-color="#9aa3aa"/>
<stop offset="1" stop-color="#c6ced4"/>
</linearGradient>
<radialGradient id="knobGrad" cx="0.34" cy="0.28" r="0.85">
<stop offset="0" stop-color="#ffffff"/>
<stop offset="0.32" stop-color="#e2e9ee"/>
<stop offset="0.68" stop-color="#9aa3aa"/>
<stop offset="1" stop-color="#545c62"/>
</radialGradient>
<!-- dark plastic lid -->
<linearGradient id="lidGrad" x1="0" y1="0" x2="1" y2="0">
<stop offset="0" stop-color="#15181b"/>
<stop offset="0.12" stop-color="#5b6167"/>
<stop offset="0.26" stop-color="#8f969d"/>
<stop offset="0.42" stop-color="#3a3e42"/>
<stop offset="0.62" stop-color="#1b1e21"/>
<stop offset="0.82" stop-color="#4a4f54"/>
<stop offset="1" stop-color="#0e1012"/>
</linearGradient>
<linearGradient id="lidTop" x1="0" y1="0" x2="0" y2="1">
<stop offset="0" stop-color="#4b5157"/>
<stop offset="0.5" stop-color="#2a2e32"/>
<stop offset="1" stop-color="#15181b"/>
</linearGradient>
<!-- glass -->
<linearGradient id="glass" x1="0" y1="0" x2="1" y2="0">
<stop offset="0" stop-color="#9fc3d6"/>
<stop offset="0.12" stop-color="#e8f4fa"/>
<stop offset="0.3" stop-color="#f9fdff"/>
<stop offset="0.52" stop-color="#dceaf2"/>
<stop offset="0.74" stop-color="#bcd7e6"/>
<stop offset="0.88" stop-color="#eaf4f9"/>
<stop offset="1" stop-color="#9dc0d4"/>
</linearGradient>
<linearGradient id="glassTop" x1="0" y1="0" x2="0" y2="1">
<stop offset="0" stop-color="#eef7fc"/>
<stop offset="0.5" stop-color="#ffffff"/>
<stop offset="1" stop-color="#cfe4ef"/>
</linearGradient>
<pattern id="meshPattern" width="6" height="6" patternUnits="userSpaceOnUse">
<rect width="6" height="6" fill="#9aa3aa"/>
<path d="M0 0H6 M0 6H6 M0 0V6 M6 0V6" stroke="#656d74" stroke-width="1"/>
<path d="M0 3H6 M3 0V6" stroke="#cdd5da" stroke-width="0.6"/>
</pattern>
</defs>
<!-- ============ background ============ -->
<rect x="0" y="0" width="960" height="1330" fill="#fbfbf9"/>
<rect x="10" y="10" width="940" height="1310" rx="10" fill="none" stroke="#e3e3df" stroke-width="1.5"/>
<!-- ============ title ============ -->
<text x="34" y="50" font-family="Helvetica, Arial, sans-serif" font-size="26" font-weight="bold" fill="#22262a">French Press — Exploded Assembly View</text>
<text x="34" y="74" font-family="Helvetica, Arial, sans-serif" font-size="14" fill="#6d757c">Standard three-piece plunger filter (top plate · mesh screen · bottom plate)</text>
<g transform="translate(0,120)">
<!-- ============ assembly axis ============ -->
<line x1="340" y1="70" x2="340" y2="1110" stroke="#cfcfca" stroke-width="1.2" stroke-dasharray="7 9"/>
<!-- ============ ground shadow ============ -->
<ellipse cx="340" cy="1112" rx="92" ry="12" fill="#c9cfd3" opacity="0.45"/>
<!-- ============================ CARAFE ============================ -->
<g id="carafe">
<!-- body -->
<path d="M264 760 L264 1105 A76 16 0 0 0 416 1105 L416 760 Z" fill="url(#glass)" stroke="#9dbccd" stroke-width="1.2"/>
<!-- bottom ellipse -->
<ellipse cx="340" cy="1105" rx="76" ry="16" fill="url(#glass)" stroke="#9dbccd" stroke-width="1.2"/>
<!-- reinforce bottom curve -->
<path d="M264 1105 A76 16 0 0 0 416 1105" fill="none" stroke="#8fb2c4" stroke-width="2"/>
<!-- top rim -->
<ellipse cx="340" cy="760" rx="76" ry="16" fill="url(#glassTop)" stroke="#9dbccd" stroke-width="1.2"/>
<ellipse cx="340" cy="760" rx="67" ry="13" fill="#eef5f9" stroke="#bcd3e0" stroke-width="1"/>
<ellipse cx="340" cy="762" rx="67" ry="13" fill="none" stroke="#cfe2ec" stroke-width="2"/>
<!-- glass highlights -->
<path d="M283 772 L283 1092" stroke="#ffffff" stroke-width="6" opacity="0.65" stroke-linecap="round"/>
<path d="M398 780 L398 1090" stroke="#ffffff" stroke-width="3" opacity="0.4" stroke-linecap="round"/>
<!-- pouring spout on rim (left) -->
<path d="M272 755 C 254 753 240 743 247 729 C 257 743 276 750 302 752 C 290 757 280 757 272 755 Z"
fill="url(#glassTop)" stroke="#9dbccd" stroke-width="1.2"/>
<path d="M249 733 C 258 744 274 750 298 752" fill="none" stroke="#ffffff" stroke-width="1.5" opacity="0.8"/>
</g>
<!-- ============================ HANDLE ============================ -->
<g id="handle">
<path d="M412 846 C 508 858, 508 972, 412 986" fill="none" stroke="url(#chrome)" stroke-width="15" stroke-linecap="round"/>
<path d="M412 846 C 508 858, 508 972, 412 986" fill="none" stroke="#6f787f" stroke-width="1" opacity="0.5"/>
<ellipse cx="413" cy="846" rx="9" ry="11" fill="#3a3e42" stroke="#1c1f22" stroke-width="1"/>
<ellipse cx="413" cy="986" rx="9" ry="11" fill="#3a3e42" stroke="#1c1f22" stroke-width="1"/>
</g>
<!-- ============================ PLUNGER / FILTER STACK ============================ -->
<!-- BOTTOM PLATE -->
<g id="bottom-plate">
<path d="M274 636 L274 648 A66 12 0 0 0 406 648 L406 636" fill="url(#chrome)" stroke="#7f888f" stroke-width="0.8"/>
<ellipse cx="340" cy="636" rx="66" ry="12" fill="url(#chromeTop)" stroke="#7f888f" stroke-width="0.8"/>
<ellipse cx="340" cy="636" rx="11" ry="3.4" fill="#565e64"/>
<g fill="#6f787f">
<ellipse cx="380" cy="636.5" rx="3.2" ry="1.2"/>
<ellipse cx="368.3" cy="641.2" rx="3.2" ry="1.2"/>
<ellipse cx="340" cy="643.4" rx="3.2" ry="1.2"/>
<ellipse cx="311.7" cy="641.2" rx="3.2" ry="1.2"/>
<ellipse cx="300" cy="636.5" rx="3.2" ry="1.2"/>
<ellipse cx="311.7" cy="631.8" rx="3.2" ry="1.2"/>
<ellipse cx="340" cy="629.6" rx="3.2" ry="1.2"/>
<ellipse cx="368.3" cy="631.8" rx="3.2" ry="1.2"/>
</g>
</g>
<!-- MESH SCREEN -->
<g id="mesh-screen">
<path d="M276 596 L276 602 A64 11 0 0 0 404 602 L404 596" fill="url(#chrome)" stroke="#6f787f" stroke-width="0.8"/>
<ellipse cx="340" cy="596" rx="64" ry="11" fill="url(#meshPattern)" stroke="#e3e9ed" stroke-width="2"/>
<ellipse cx="340" cy="596" rx="64" ry="11" fill="none" stroke="#7f888f" stroke-width="1"/>
<ellipse cx="340" cy="596" rx="9" ry="2.8" fill="#565e64"/>
<ellipse cx="322" cy="591" rx="16" ry="4" fill="#ffffff" opacity="0.25"/>
</g>
<!-- TOP PLATE -->
<g id="top-plate">
<path d="M274 560 L274 572 A66 12 0 0 0 406 572 L406 560" fill="url(#chrome)" stroke="#7f888f" stroke-width="0.8"/>
<ellipse cx="340" cy="560" rx="66" ry="12" fill="url(#chromeTop)" stroke="#7f888f" stroke-width="0.8"/>
<ellipse cx="340" cy="560" rx="10" ry="3.2" fill="#565e64"/>
<g fill="#6f787f">
<ellipse cx="380" cy="560.5" rx="3.2" ry="1.2"/>
<ellipse cx="368.3" cy="565.2" rx="3.2" ry="1.2"/>
<ellipse cx="340" cy="567.4" rx="3.2" ry="1.2"/>
<ellipse cx="311.7" cy="565.2" rx="3.2" ry="1.2"/>
<ellipse cx="300" cy="560.5" rx="3.2" ry="1.2"/>
<ellipse cx="311.7" cy="555.8" rx="3.2" ry="1.2"/>
<ellipse cx="340" cy="553.6" rx="3.2" ry="1.2"/>
<ellipse cx="368.3" cy="555.8" rx="3.2" ry="1.2"/>
</g>
</g>
<!-- ============================ LID ============================ -->
<g id="lid">
<!-- lower ellipse -->
<ellipse cx="340" cy="496" rx="80" ry="14" fill="url(#lidGrad)" stroke="#0d0f11" stroke-width="1"/>
<!-- side band -->
<path d="M260 478 L260 496 A80 14 0 0 0 420 496 L420 478 Z" fill="url(#lidGrad)" stroke="#0d0f11" stroke-width="1"/>
<!-- top face -->
<ellipse cx="340" cy="478" rx="80" ry="14" fill="url(#lidTop)" stroke="#0d0f11" stroke-width="1"/>
<!-- raised collar around rod hole -->
<path d="M324 460 L324 478 A16 5 0 0 0 356 478 L356 460 Z" fill="url(#lidGrad)" stroke="#0d0f11" stroke-width="0.8"/>
<ellipse cx="340" cy="460" rx="16" ry="5" fill="#4b5157" stroke="#0d0f11" stroke-width="0.8"/>
<ellipse cx="340" cy="460" rx="7" ry="2.4" fill="#0a0b0c"/>
<!-- pour spout lip -->
<path d="M260 478 q-16 -1 -22 -11 q12 3 22 -1 z" fill="url(#lidGrad)" stroke="#0d0f11" stroke-width="0.8"/>
<!-- sheen -->
<ellipse cx="312" cy="474" rx="26" ry="4" fill="#ffffff" opacity="0.18"/>
</g>
<!-- ============================ PLUNGER ROD ============================ -->
<g id="rod">
<rect x="334.5" y="112" width="11" height="336" rx="3" fill="url(#chrome)" stroke="#7f888f" stroke-width="0.6"/>
<ellipse cx="340" cy="112" rx="5.5" ry="2.4" fill="#cfd7dc"/>
<ellipse cx="340" cy="448" rx="5.5" ry="2.4" fill="#8b949c"/>
<rect x="336" y="116" width="2" height="326" fill="#ffffff" opacity="0.5"/>
</g>
<!-- ============================ KNOB ============================ -->
<g id="knob">
<rect x="332" y="96" width="16" height="28" rx="4" fill="url(#chrome)" stroke="#6f787f" stroke-width="0.7"/>
<circle cx="340" cy="80" r="30" fill="url(#knobGrad)" stroke="#6f787f" stroke-width="1"/>
<ellipse cx="329" cy="69" rx="9" ry="6" fill="#ffffff" opacity="0.65"/>
<path d="M318 92 a30 30 0 0 0 44 0" fill="none" stroke="#6f787f" stroke-width="1" opacity="0.6"/>
</g>
<!-- ============================ LEADERS & LABELS ============================ -->
<g font-family="Helvetica, Arial, sans-serif" font-size="18" fill="#26292d">
<g stroke="#8b949c" stroke-width="1.2" fill="none">
<line x1="370" y1="66" x2="540" y2="62"/>
<line x1="346" y1="300" x2="540" y2="300"/>
<line x1="420" y1="482" x2="540" y2="470"/>
<line x1="406" y1="560" x2="540" y2="556"/>
<line x1="404" y1="596" x2="540" y2="596"/>
<line x1="406" y1="636" x2="540" y2="634"/>
<line x1="508" y1="915" x2="540" y2="915"/>
<line x1="416" y1="1078" x2="540" y2="1078"/>
</g>
<g fill="#8b949c">
<circle cx="370" cy="66" r="2.6"/>
<circle cx="346" cy="300" r="2.6"/>
<circle cx="420" cy="482" r="2.6"/>
<circle cx="406" cy="560" r="2.6"/>
<circle cx="404" cy="596" r="2.6"/>
<circle cx="406" cy="636" r="2.6"/>
<circle cx="508" cy="915" r="2.6"/>
<circle cx="416" cy="1078" r="2.6"/>
</g>
<text x="550" y="68">Plunger knob</text>
<text x="550" y="306">Plunger rod</text>
<text x="550" y="476">Lid (with rod collar)</text>
<text x="550" y="562">Top filter plate</text>
<text x="550" y="602">Mesh screen</text>
<text x="550" y="640">Bottom filter plate</text>
<text x="550" y="921">Carafe handle</text>
<text x="550" y="1084">Glass carafe</text>
</g>
</g><!-- /exploded stack -->
<!-- assembly note -->
<g font-family="Helvetica, Arial, sans-serif" font-size="13" fill="#7a8288">
<text x="34" y="1288">Exploded along the vertical axis. Dashed line = assembly axis.</text>
<text x="34" y="1308">The rod passes through the lid collar; the top plate, mesh screen and bottom plate stack and fasten onto its lower end.</text>
</g>
</svg>round 1 of 3
Two identical perforated plates either side of the mesh, so the order has nothing to read. No base on the carafe.
modeldeepseek/deepseek-v4.1-flashtasksvg-french-press@v2date2026-09-22rounds3 of 8 allowedcost$0.0418thinkingmediumtokens259,179 in, 23,281 out, of which 17,069 reasoningtime7 min 12 s
All seven partsdecided by looking · Pass if all seven are drawn as separate shapes and each has a label naming it. A part that is only named in a label or a comment, with nothing drawn, fails it.pass
Stack orderdecided by a number, from the filen/d
Filter fits the glassdecided by a number, from the filepass
One assembly axisdecided by looking · Pass if one vertical line runs through the middle of every part, and every leader line leaves from the same side. One part pushed off to the side fails it.pass
Labels matchdecided by looking · Pass if following each leader line from its label ends on the part that label names. One label pointing at the wrong part, or at nothing, fails it.pass
There is no post about this one, since only some results need one, so the picture, the source and the scoring are here instead.
Draw an exploded assembly diagram of a French press, as an SVG. Use the standard three-piece plunger filter rather than a two-piece travel press.Frozen at v2. This model got this and nothing else.
The standard three-piece plunger, from the top down: spiral (spring) plate, mesh screen, cross-plate. The cross-plate is the bottom piece, because its threaded stem is what the rod screws into. The spiral plate above the mesh is what presses the mesh edge out against the glass. Checked against the WebstaurantStore anatomy diagram, which is drawn exploded and labelled, and against each part's y coordinate in the SVG rather than its comment. Two-piece travel presses exist and stack differently, which is why v2 of the prompt names the design. How it is scored, and this run's files on GitHub.
