SVG: exploded French press, by glm-5.3-flashx — glm-5.3-flashx · round 3 of 3 · seed 2$0.01SVG PNG press.svg

Exploded French press, by GLM 5.3 FlashX, the render after round 1 — 123What the model saw after each round. The picture above is the round that was scored, round 3.

gallery/Exploded French press/GLM 5.3 FlashX, run 2

Calls its top piece a spiral cross plate and puts the mesh at the bottom, with the lid below the whole filter and every plate wider than the carafe.

modelz-ai/glm-5.3-flashxtasksvg-french-press@v2date2026-09-22rounds3 of 8 allowedcost$0.0111thinkingmediumtokens55,198 in, 3,660 out, of which 452 reasoningtime1 min 4 sfailurepart-order · physical-plausibility

All seven partsdecided by looking · Pass if all seven are drawn as separate shapes and each has a label naming it. A part that is only named in a label or a comment, with nothing drawn, fails it.pass

Stack orderdecided by a number, from the filefail

Filter fits the glassdecided by a number, from the filefail

One assembly axisdecided by looking · Pass if one vertical line runs through the middle of every part, and every leader line leaves from the same side. One part pushed off to the side fails it.pass

Labels matchdecided by looking · Pass if following each leader line from its label ends on the part that label names. One label pointing at the wrong part, or at nothing, fails it.pass

There is no post about this one, since only some results need one, so the picture, the source and the scoring are here instead.

its other runs

Exploded French press, by GLM 5.3 FlashX, run 1

run 1 · 4r · $0.0203Three filter pieces labelled as one assembly, so which plate is which cannot be read, and all three are under 80% of the glass width.

Exploded French press, by GLM 5.3 FlashX, run 3

run 3 · 4r · $0.0191A plate missing, the cross-plate above the mesh, the lid below the filter, and plates wider than the carafe.

same prompt, other modelsall 33 runs on Exploded French press →

the prompt it was given

Draw an exploded assembly diagram of a French press, as an SVG. Use the standard three-piece plunger filter rather than a two-piece travel press.

Frozen at v2. This model got this and nothing else.

ground truth

The standard three-piece plunger, from the top down: spiral (spring) plate, mesh screen, cross-plate. The cross-plate is the bottom piece, because its threaded stem is what the rod screws into. The spiral plate above the mesh is what presses the mesh edge out against the glass. Checked against the WebstaurantStore anatomy diagram, which is drawn exploded and labelled, and against each part's y coordinate in the SVG rather than its comment. Two-piece travel presses exist and stack differently, which is why v2 of the prompt names the design. How it is scored, and this run's files on GitHub.
