TikZ: a three-set coffee Venn diagram, by perceptron-mk1.5
perceptron-mk1.5 · round 2 of 2 · seed 3$0.17SVGPNGPDFvenn.tex
venn.tex · 41 lines
\documentclass[tikz,border=10pt]{standalone}
\usepackage{tikz}
\begin{document}
\begin{tikzpicture}[font=\sffamily, every node/.style={font=\sffamily\small}]
  % Define circle centers
  \coordinate (A) at (0,0);   % Has espresso
  \coordinate (B) at (2,0);    % Has milk
  \coordinate (C) at (1,1.732); % Served cold

  % Draw circles with labels
  \draw[fill=blue!10] (A) circle (1.5cm) node[pos=0.5, below left] {Has espresso};
  \draw[fill=red!10] (B) circle (1.5cm) node[pos=0.5, below right] {Has milk};
  \draw[fill=green!10] (C) circle (1.5cm) node[pos=0.5, above] {Served cold};

  % Place drinks in correct regions
  % Espresso only (left, not overlapping)
  \node at (-0.8, -0.2) {short black};
  \node at (-0.8, 0.2) {pour-over};

  % Milk only (right, not overlapping)
  \node at (2.8, -0.2) {milkshake};

  % Cold only (top, not overlapping)
  \node at (1, 2.8) {cold brew};

  % Espresso ∩ Milk (bottom overlap)
  \node at (1, -0.8) {flat white};
  \node at (1, -1.2) {babyccino};

  % Espresso ∩ Cold (left-top overlap)
  \node at (0.2, 1.2) {iced long black};

  % Milk ∩ Cold (right-top overlap)
  \node at (1.8, 1.2) {milkshake};

  % All three (center)
  \node at (1, 0.5) {iced latte};

\end{tikzpicture}
\end{document}

A three-set coffee Venn diagram: Perceptron Mk1.5

modelperceptron/perceptron-mk1.5tasktikz-coffee-venn@v1date2026-09-27rounds2 of 8 allowedcost$0.1688thinkingmediumtokens859,748 in, 26,547 out, of which 1,785 reasoningtime4 min 1 sfailurelabelling
Compilesdecided by a number, from the filepass
Seven regions, three namesdecided by a number, from the filepass
Every drink in its regiondecided by a number, from the filefail
No label on an edgedecided by a number, from the filefail

There is no post about this one, since only some results need one, so the picture, the source and the scoring are here instead.

its other runs
the prompt it was given
Using LaTeX and TikZ, draw a Venn diagram of three overlapping circles labelled "Has espresso", "Has milk" and "Served cold". Write each of these drinks in the region where it belongs: short black, flat white, iced latte, iced long black, cold brew, babyccino, milkshake, pour-over.
Frozen at v1. This model got this and nothing else.
ground truth

Short black is espresso only, flat white espresso and milk, iced long black espresso and cold, iced latte all three, babyccino milk only, milkshake milk and cold, cold brew cold only, and pour-over outside every circle. The circles and words are read back out of the compiled PDF, each word has to be centred in its own region, and no letter may touch a circle's outline, with the line's width counted. How it is scored, and this run's files on GitHub.
