press.svg · 156 lines
<svg xmlns="http://www.w3.org/2000/svg" width="760" height="1400" viewBox="0 0 760 1400" font-family="Helvetica, Arial, sans-serif">
<defs>
<pattern id="mesh" width="5" height="5" patternUnits="userSpaceOnUse">
<path d="M0 0L5 5M5 0L0 5" stroke="#777" stroke-width="0.6"/>
</pattern>
<linearGradient id="steel" x1="0" x2="1">
<stop offset="0" stop-color="#9aa3ab"/><stop offset="0.4" stop-color="#eef1f3"/><stop offset="1" stop-color="#7d868e"/>
</linearGradient>
<linearGradient id="glass" x1="0" x2="1">
<stop offset="0" stop-color="#cfe6f2" stop-opacity="0.8"/><stop offset="0.25" stop-color="#ffffff" stop-opacity="0.6"/><stop offset="1" stop-color="#b8d6e6" stop-opacity="0.8"/>
</linearGradient>
<marker id="dot" markerWidth="6" markerHeight="6" refX="3" refY="3"><circle cx="3" cy="3" r="2" fill="#222"/></marker>
</defs>
<rect width="760" height="1400" fill="#fff"/>
<text x="380" y="34" text-anchor="middle" font-size="22" font-weight="bold">French Press — Exploded Assembly</text>
<!-- assembly axis -->
<line x1="300" y1="60" x2="300" y2="1370" stroke="#c33" stroke-width="1" stroke-dasharray="12 4 2 4"/>
<!-- 1 Knob -->
<g stroke="#222" stroke-width="1.5">
<path d="M276 100 Q272 64 300 60 Q328 64 324 100 Z" fill="#333"/>
<rect x="290" y="100" width="20" height="10" fill="#555"/>
</g>
<!-- 2 Lid -->
<g stroke="#222" stroke-width="1.5">
<path d="M215 175 L215 195 A85 16 0 0 0 385 195 L385 175" fill="url(#steel)"/>
<ellipse cx="300" cy="175" rx="85" ry="16" fill="#dde2e6"/>
<path d="M240 172 Q300 135 360 172" fill="url(#steel)"/>
<ellipse cx="300" cy="148" rx="9" ry="3" fill="#333"/>
<!-- pour spout notch -->
<path d="M378 182 L395 178 L392 190 L384 196" fill="#cfd4d8"/>
</g>
<!-- 3 Plunger rod -->
<g stroke="#222" stroke-width="1.5">
<rect x="295" y="240" width="10" height="290" fill="url(#steel)"/>
<path d="M295 240 L305 240" />
<!-- threads top -->
<path d="M295 246h10M295 251h10M295 256h10" stroke-width="0.8"/>
<!-- threads bottom -->
<path d="M295 515h10M295 520h10M295 525h10" stroke-width="0.8"/>
</g>
<!-- 4 Spiral plate -->
<g stroke="#222" stroke-width="1.5">
<path d="M212 590 L212 598 A88 15 0 0 0 388 598 L388 590" fill="url(#steel)"/>
<ellipse cx="300" cy="590" rx="88" ry="15" fill="#e3e7ea"/>
<ellipse cx="300" cy="590" rx="78" ry="12" fill="none" stroke-width="0.8"/>
<ellipse cx="300" cy="590" rx="10" ry="3" fill="#888"/>
<!-- spiral spring around edge -->
<path d="M300 590 m14 0 a14 3 0 1 1 -28 0 a28 5.5 0 1 1 56 0 a42 7.5 0 1 1 -84 0 a56 9.5 0 1 1 112 0 a70 11 0 1 1 -140 0" fill="none" stroke="#666" stroke-width="0.8"/>
<path d="M212 596 C230 610 260 614 300 614 C340 614 370 610 388 596" fill="none" stroke-width="2" stroke-dasharray="3 2"/>
</g>
<!-- 5 Mesh screen -->
<g stroke="#222" stroke-width="1.5">
<ellipse cx="300" cy="660" rx="92" ry="16" fill="url(#mesh)"/>
<ellipse cx="300" cy="660" rx="92" ry="16" fill="none" stroke-width="2.5"/>
<ellipse cx="300" cy="660" rx="9" ry="3" fill="#fff"/>
</g>
<!-- 6 Cross plate -->
<g stroke="#222" stroke-width="1.5">
<path d="M215 730 L215 736 A85 14 0 0 0 385 736 L385 730" fill="url(#steel)"/>
<ellipse cx="300" cy="730" rx="85" ry="14" fill="#e3e7ea"/>
<g fill="#fff" stroke-width="1">
<path d="M300 730 L232 724 A72 11 0 0 1 292 719 Z"/>
<path d="M300 730 L308 719 A72 11 0 0 1 368 724 Z"/>
<path d="M300 730 L368 736 A72 11 0 0 1 308 741 Z"/>
<path d="M300 730 L292 741 A72 11 0 0 1 232 736 Z"/>
</g>
<ellipse cx="300" cy="730" rx="10" ry="3.5" fill="#888"/>
</g>
<!-- 7 Retaining nut -->
<g stroke="#222" stroke-width="1.5">
<polygon points="288,790 312,790 318,800 312,810 288,810 282,800" fill="url(#steel)"/>
<path d="M296 790 L296 810 M304 790 L304 810" stroke-width="0.8"/>
</g>
<!-- 8 Glass beaker -->
<g stroke="#222" stroke-width="1.5">
<path d="M205 880 L205 1110 A95 16 0 0 0 395 1110 L395 880" fill="url(#glass)"/>
<ellipse cx="300" cy="880" rx="95" ry="16" fill="#eaf5fb"/>
<path d="M388 872 L412 866 L400 886" fill="#eaf5fb"/>
<path d="M225 905 L225 1090" stroke="#fff" stroke-width="5" opacity="0.9"/>
<g stroke-width="1" fill="#555" font-size="10" stroke="none">
<path d="M370 950h14M374 990h10M370 1030h14M374 1070h10" stroke="#456" stroke-width="1"/>
</g>
</g>
<!-- 9 Frame with handle -->
<g stroke="#222" stroke-width="1.5">
<!-- back band -->
<path d="M195 1180 L195 1330 A105 18 0 0 0 405 1330 L405 1180" fill="none" stroke="#999"/>
<ellipse cx="300" cy="1180" rx="105" ry="18" fill="none"/>
<!-- front straps -->
<path d="M195 1180 L195 1330" stroke-width="5" stroke="#6b737a"/>
<path d="M405 1180 L405 1330" stroke-width="5" stroke="#6b737a"/>
<path d="M195 1190 A105 18 0 0 0 405 1190" fill="none" stroke-width="7" stroke="#8a939a"/>
<path d="M195 1280 A105 18 0 0 0 405 1280" fill="none" stroke-width="5" stroke="#8a939a"/>
<!-- base -->
<path d="M190 1330 L190 1342 A110 19 0 0 0 410 1342 L410 1330" fill="url(#steel)"/>
<ellipse cx="300" cy="1330" rx="110" ry="19" fill="#c8ced3"/>
<ellipse cx="300" cy="1330" rx="98" ry="15" fill="#e8ecef"/>
<!-- feet -->
<rect x="215" y="1354" width="18" height="8" fill="#555"/><rect x="367" y="1354" width="18" height="8" fill="#555"/>
<!-- handle -->
<path d="M195 1195 C130 1195 125 1205 125 1235 L125 1290 C125 1310 140 1312 195 1310" fill="none" stroke="#222" stroke-width="16" stroke-linecap="round"/>
<path d="M195 1195 C130 1195 125 1205 125 1235 L125 1290 C125 1310 140 1312 195 1310" fill="none" stroke="#3a3a3a" stroke-width="12" stroke-linecap="round"/>
</g>
<!-- labels -->
<g font-size="15" fill="#111">
<g stroke="#222" stroke-width="1" fill="none" marker-start="url(#dot)">
<polyline points="322,82 470,82"/>
<polyline points="380,176 470,176"/>
<polyline points="305,380 470,380"/>
<polyline points="380,594 470,594"/>
<polyline points="385,664 470,664"/>
<polyline points="378,734 470,734"/>
<polyline points="316,800 470,800"/>
<polyline points="392,990 470,990"/>
<polyline points="405,1240 470,1240"/>
</g>
<g font-weight="bold">
<text x="478" y="87">1 Knob</text>
<text x="478" y="181">2 Lid</text>
<text x="478" y="385">3 Plunger rod</text>
<text x="478" y="599">4 Spiral plate</text>
<text x="478" y="669">5 Mesh filter screen</text>
<text x="478" y="739">6 Cross plate</text>
<text x="478" y="805">7 Retaining nut</text>
<text x="478" y="995">8 Glass beaker</text>
<text x="478" y="1245">9 Frame & handle</text>
</g>
<g font-size="12" fill="#555">
<text x="496" y="104">threads onto top of rod</text>
<text x="496" y="198">rod passes through center bore</text>
<text x="496" y="402">threaded both ends</text>
<text x="496" y="616">spring coil seals against glass</text>
<text x="496" y="686">fine stainless mesh</text>
<text x="496" y="756">clamps screen to spiral plate</text>
<text x="496" y="822">secures filter stack to rod</text>
<text x="496" y="1012">borosilicate, with spout</text>
<text x="496" y="1262">beaker drops into frame</text>
</g>
<!-- bracket for filter assembly -->
<path d="M190 575 L180 575 L180 812 L190 812" fill="none" stroke="#222"/>
<text x="172" y="690" font-size="13" text-anchor="end" font-style="italic">3-piece</text>
<text x="172" y="706" font-size="13" text-anchor="end" font-style="italic">filter</text>
</g>
</svg>Exploded French press: Opus 5.5
modelanthropic/claude-opus-5.5tasksvg-french-press@v2date2026-10-01rounds2 of 8 allowedcost$0.1625
All seven partsdecided by looking · Pass if all seven are drawn as separate shapes and each has a label naming it. A part that is only named in a label or a comment, with nothing drawn, fails it.pass
Stack orderdecided by a number, from the filepass
Filter fits the glassdecided by a number, from the filepass
One assembly axisdecided by looking · Pass if one vertical line runs through the middle of every part, and every leader line leaves from the same side. One part pushed off to the side fails it.pass
Labels matchdecided by looking · Pass if following each leader line from its label ends on the part that label names. One label pointing at the wrong part, or at nothing, fails it.pass
There is no post about this one, since only some results need one, so the picture, the source and the scoring are here instead.
run 1 · 3r · $0.2115The cleanest press on the bench, with the cross-plate on top of the mesh.
run 1 · 3r · $0.2307
run 2 · 2r · $0.2084The stack the right way up in two rounds, with the frame drawn beside the glass instead of under it.
run 3 · 3r · $0.2209Right in round 1, then it swapped the plates, and its filter is wider than the glass.same prompt, other modelsall 33 runs on Exploded French press →
Draw an exploded assembly diagram of a French press, as an SVG. Use the standard three-piece plunger filter rather than a two-piece travel press.Frozen at v2. This model got this and nothing else.
The standard three-piece plunger, from the top down: spiral (spring) plate, mesh screen, cross-plate. The cross-plate is the bottom piece, because its threaded stem is what the rod screws into. The spiral plate above the mesh is what presses the mesh edge out against the glass. Checked against the WebstaurantStore anatomy diagram, which is drawn exploded and labelled, and against each part's y coordinate in the SVG rather than its comment. Two-piece travel presses exist and stack differently, which is why v2 of the prompt names the design. How it is scored, and this run's files on GitHub.
