press.svg · 136 lines
<svg xmlns="http://www.w3.org/2000/svg" width="1400" height="1000" viewBox="0 0 1400 1000" role="img" aria-labelledby="title desc">
<title id="title">Exploded assembly diagram of a French press</title>
<desc id="desc">A technical exploded view showing knob and plunger rod, lid, glass carafe, spiral spring plate, fine mesh screen, and cross plate arranged on a central assembly axis.</desc>
<defs>
<linearGradient id="paper" x1="0" y1="0" x2="1" y2="1"><stop stop-color="#f8f6f0"/><stop offset="1" stop-color="#e9eef0"/></linearGradient>
<linearGradient id="steel" x1="0" y1="0" x2="1" y2="0"><stop stop-color="#4c5960"/><stop offset=".18" stop-color="#d8e0e2"/><stop offset=".38" stop-color="#68767b"/><stop offset=".62" stop-color="#f6f8f7"/><stop offset=".82" stop-color="#68757a"/><stop offset="1" stop-color="#303b40"/></linearGradient>
<linearGradient id="darkSteel" x1="0" y1="0" x2="1" y2="0"><stop stop-color="#202c31"/><stop offset=".45" stop-color="#859298"/><stop offset=".7" stop-color="#334047"/><stop offset="1" stop-color="#182126"/></linearGradient>
<linearGradient id="glass" x1="0" y1="0" x2="1" y2="0"><stop stop-color="#b9e4ea" stop-opacity=".18"/><stop offset=".14" stop-color="#fff" stop-opacity=".62"/><stop offset=".28" stop-color="#b5dfe6" stop-opacity=".15"/><stop offset=".76" stop-color="#fff" stop-opacity=".52"/><stop offset=".9" stop-color="#90c5cf" stop-opacity=".2"/><stop offset="1" stop-color="#6697a0" stop-opacity=".35"/></linearGradient>
<radialGradient id="knob" cx="35%" cy="24%"><stop stop-color="#66757c"/><stop offset=".35" stop-color="#2f3b41"/><stop offset="1" stop-color="#11191d"/></radialGradient>
<pattern id="mesh" width="7" height="7" patternUnits="userSpaceOnUse" patternTransform="scale(1 .55) rotate(25)"><path d="M0 0H7M0 0V7" fill="none" stroke="#53656a" stroke-width=".75" opacity=".85"/></pattern>
<pattern id="grid" width="40" height="40" patternUnits="userSpaceOnUse"><path d="M40 0H0V40" fill="none" stroke="#234c56" stroke-width=".5" opacity=".065"/></pattern>
<filter id="shadow" x="-30%" y="-30%" width="160%" height="180%"><feGaussianBlur in="SourceAlpha" stdDeviation="8"/><feOffset dy="6"/><feComponentTransfer><feFuncA type="linear" slope=".18"/></feComponentTransfer><feMerge><feMergeNode/><feMergeNode in="SourceGraphic"/></feMerge></filter>
<filter id="soft"><feGaussianBlur stdDeviation="3"/></filter>
<marker id="arrow" markerWidth="9" markerHeight="9" refX="5" refY="4.5" orient="auto"><path d="M0 0L9 4.5 0 9z" fill="#c65d3b"/></marker>
<style>
.outline{stroke:#273b42;stroke-width:3;stroke-linejoin:round;stroke-linecap:round}
.fine{stroke:#52686f;stroke-width:1.5;fill:none}
.label{font-family:Arial,sans-serif;font-size:18px;font-weight:700;letter-spacing:.5px;fill:#263c43}
.sub{font-family:Arial,sans-serif;font-size:13px;letter-spacing:1px;fill:#5f747a}
.num{font-family:Arial,sans-serif;font-size:15px;font-weight:700;fill:#fff;text-anchor:middle;dominant-baseline:middle}
.call{stroke:#71868b;stroke-width:1.5;fill:none}
</style>
</defs>
<rect width="1400" height="1000" fill="url(#paper)"/>
<rect width="1400" height="1000" fill="url(#grid)"/>
<path d="M38 84V38h46M1316 38h46v46M38 916v46h46M1362 916v46h-46" fill="none" stroke="#789097" stroke-width="2" opacity=".55"/>
<!-- Header -->
<text x="74" y="86" font-family="Arial,sans-serif" font-size="36" font-weight="700" letter-spacing="2" fill="#20363d">FRENCH PRESS</text>
<text x="76" y="116" class="sub">EXPLODED ASSEMBLY / STANDARD THREE-PIECE PLUNGER FILTER</text>
<path d="M76 136H410" stroke="#c65d3b" stroke-width="4"/><text x="1230" y="82" class="sub" text-anchor="end">ASSEMBLY No. FP–03</text><text x="1230" y="106" class="sub" text-anchor="end">SCALE: DIAGRAMMATIC</text>
<!-- centerline / down direction -->
<path d="M700 132V930" stroke="#c65d3b" stroke-width="1.5" stroke-dasharray="10 8" opacity=".65"/>
<path d="M1260 195V810" stroke="#c65d3b" stroke-width="2" marker-end="url(#arrow)" opacity=".85"/>
<text x="1284" y="494" class="sub" transform="rotate(90 1284 494)" text-anchor="middle" fill="#c65d3b">EXPLODED STACK ORDER</text>
<!-- Knob and rod -->
<g filter="url(#shadow)">
<ellipse cx="700" cy="174" rx="51" ry="20" fill="#121b1f" class="outline"/>
<path d="M650 172c2-34 20-51 50-51s48 17 50 51c-5 13-24 21-50 21s-45-8-50-21z" fill="url(#knob)" class="outline"/>
<path d="M671 145c10-14 24-18 41-15" fill="none" stroke="#a8b4b7" stroke-width="4" stroke-linecap="round" opacity=".38"/>
<rect x="694" y="191" width="12" height="500" rx="5" fill="url(#steel)" stroke="#35464c" stroke-width="2"/>
<path d="M697 206V667" stroke="#fff" stroke-width="2" opacity=".62"/>
<path d="M692 670h16v25h-16z" fill="url(#steel)" class="outline"/>
<path d="M692 675h16m-16 6h16m-16 6h16" stroke="#273b42" stroke-width="1.4"/>
</g>
<!-- Lid -->
<g filter="url(#shadow)">
<ellipse cx="700" cy="266" rx="151" ry="31" fill="url(#steel)" class="outline"/>
<path d="M549 265v28c0 18 68 32 151 32s151-14 151-32v-28c-12 18-73 29-151 29s-139-11-151-29z" fill="url(#darkSteel)" class="outline"/>
<ellipse cx="700" cy="264" rx="139" ry="23" fill="none" stroke="#ecf1f2" stroke-width="2" opacity=".45"/>
<ellipse cx="700" cy="264" rx="13" ry="6" fill="#182328" stroke="#d8e1e3" stroke-width="2"/>
<path d="M572 282c35 19 220 21 257-1" fill="none" stroke="#b9c6c9" stroke-width="2" opacity=".55"/>
</g>
<!-- separation arrow -->
<path d="M700 333v24" stroke="#c65d3b" stroke-width="2" marker-end="url(#arrow)"/>
<!-- Beaker/carafe shadow -->
<ellipse cx="705" cy="669" rx="177" ry="20" fill="#43565b" opacity=".12" filter="url(#soft)"/>
<!-- handle behind body -->
<g filter="url(#shadow)">
<path d="M839 403c85-4 137 20 139 90l-1 64c-2 68-52 96-137 88l2-51c54 4 75-12 77-48v-46c-1-34-25-48-78-45z" fill="url(#knob)" class="outline"/>
<path d="M857 429c63 1 91 20 91 66v58c-3 45-37 70-93 66" fill="none" stroke="#78858a" stroke-width="5" opacity=".45"/>
<path d="M848 408l25 7v219l-28 8z" fill="#172126" stroke="#26373d" stroke-width="2"/>
</g>
<!-- glass vessel -->
<g>
<path d="M550 390L565 635c2 28 61 47 135 47s133-19 135-47l15-245z" fill="url(#glass)" class="outline"/>
<ellipse cx="700" cy="390" rx="150" ry="34" fill="#dff5f7" fill-opacity=".25" class="outline"/>
<ellipse cx="700" cy="391" rx="138" ry="24" fill="#f9ffff" fill-opacity=".32" stroke="#6f949b" stroke-width="2"/>
<path d="M567 404l13 222c1 14 20 27 48 35" fill="none" stroke="#fff" stroke-width="8" opacity=".68"/>
<path d="M601 410l11 194" fill="none" stroke="#fff" stroke-width="3" opacity=".5"/>
<path d="M825 405l-12 224c-2 13-14 22-33 30" fill="none" stroke="#6da0a9" stroke-width="3" opacity=".35"/>
<path d="M566 635c5 28 62 47 134 47s129-19 134-47" fill="none" stroke="#496b72" stroke-width="3"/>
<ellipse cx="700" cy="636" rx="134" ry="34" fill="#b7e2e6" fill-opacity=".12" stroke="#75979d" stroke-width="1.5" opacity=".75"/>
<!-- metal upper collar -->
<path d="M550 390v28c25 17 81 27 150 27s125-10 150-27v-28c-27 20-83 31-150 31s-123-11-150-31z" fill="url(#steel)" fill-opacity=".92" class="outline"/>
<path d="M566 408c34 14 83 20 134 20s100-6 134-20" fill="none" stroke="#e8eeee" stroke-width="2" opacity=".65"/>
</g>
<!-- filter connection spacing -->
<path d="M700 699v24" stroke="#c65d3b" stroke-width="2" marker-end="url(#arrow)"/>
<!-- spiral spring plate -->
<g filter="url(#shadow)">
<ellipse cx="700" cy="746" rx="137" ry="30" fill="#eef2f1" stroke="#36494f" stroke-width="3"/>
<ellipse cx="700" cy="746" rx="116" ry="22" fill="#c9d2d3" stroke="#53686d" stroke-width="2"/>
<ellipse cx="700" cy="746" rx="21" ry="8" fill="#485a60" stroke="#26393f" stroke-width="2"/>
<!-- radial support wires -->
<g stroke="#596a70" stroke-width="3">
<path d="M679 744l-92-10M681 750l-78 13M691 738l-39-17M709 738l39-17M719 744l94-10M719 750l78 13"/>
</g>
<!-- coil spring around rim -->
<path d="M570 746c7-22 19 22 26 0s19 22 26 0 19 22 26 0 19 22 26 0 19 22 26 0 19 22 26 0 19 22 26 0 19 22 26 0 19 22 26 0 19 22 26 0 19 22 26 0" fill="none" stroke="#26383e" stroke-width="5" stroke-linecap="round"/>
<path d="M574 739c33-25 218-25 252 0" fill="none" stroke="#f8ffff" stroke-width="2" opacity=".55"/>
</g>
<path d="M700 781v17" stroke="#c65d3b" stroke-width="2" marker-end="url(#arrow)"/>
<!-- mesh disc -->
<g filter="url(#shadow)">
<ellipse cx="700" cy="822" rx="133" ry="29" fill="#d7dede" class="outline"/>
<ellipse cx="700" cy="822" rx="124" ry="24" fill="url(#mesh)" stroke="#43575d" stroke-width="2"/>
<ellipse cx="700" cy="822" rx="13" ry="5" fill="#25363c"/>
<ellipse cx="700" cy="822" rx="128" ry="27" fill="none" stroke="#f0f3f2" stroke-width="2" opacity=".7"/>
</g>
<path d="M700 854v16" stroke="#c65d3b" stroke-width="2" marker-end="url(#arrow)"/>
<!-- cross plate -->
<g filter="url(#shadow)">
<ellipse cx="700" cy="894" rx="126" ry="28" fill="url(#steel)" class="outline"/>
<ellipse cx="700" cy="894" rx="115" ry="21" fill="#b9c4c6" stroke="#465b61" stroke-width="1.5"/>
<path d="M588 890l99-2 8-16h10l8 16 99 2v8l-99 2-8 16h-10l-8-16-99-2z" fill="url(#darkSteel)" stroke="#2f4248" stroke-width="2"/>
<ellipse cx="700" cy="894" rx="15" ry="7" fill="#e9eeee" stroke="#26383e" stroke-width="3"/>
<path d="M650 879l25 9m75-9l-25 9" stroke="#edf2f2" stroke-width="2" opacity=".55"/>
</g>
<!-- left labels -->
<g>
<path class="call" d="M650 156H430l-28-18H210"/><circle cx="650" cy="156" r="4" fill="#c65d3b"/><circle cx="188" cy="138" r="17" fill="#c65d3b"/><text x="188" y="138" class="num">1</text><text x="220" y="134" class="label">KNOB + PLUNGER ROD</text><text x="220" y="154" class="sub">THREADED STAINLESS STEEL</text>
<path class="call" d="M549 280H435l-28 18H210"/><circle cx="549" cy="280" r="4" fill="#c65d3b"/><circle cx="188" cy="298" r="17" fill="#c65d3b"/><text x="188" y="298" class="num">2</text><text x="220" y="294" class="label">DOMED LID</text><text x="220" y="314" class="sub">GUIDE BORE + SKIRT</text>
<path class="call" d="M566 526H430l-28-18H210"/><circle cx="566" cy="526" r="4" fill="#c65d3b"/><circle cx="188" cy="508" r="17" fill="#c65d3b"/><text x="188" y="508" class="num">3</text><text x="220" y="504" class="label">BOROSILICATE CARAFE</text><text x="220" y="524" class="sub">HEAT-RESISTANT GLASS</text>
</g>
<!-- right labels -->
<g>
<path class="call" d="M828 741h130l27-18h176"/><circle cx="828" cy="741" r="4" fill="#c65d3b"/><circle cx="1182" cy="723" r="17" fill="#c65d3b"/><text x="1182" y="723" class="num">4</text><text x="1148" y="719" class="label" text-anchor="end">SPIRAL PLATE</text><text x="1148" y="739" class="sub" text-anchor="end">SPRING SEALS TO GLASS</text>
<path class="call" d="M826 822h132l27 0h176"/><circle cx="826" cy="822" r="4" fill="#c65d3b"/><circle cx="1182" cy="822" r="17" fill="#c65d3b"/><text x="1182" y="822" class="num">5</text><text x="1148" y="818" class="label" text-anchor="end">FINE MESH SCREEN</text><text x="1148" y="838" class="sub" text-anchor="end">COFFEE PARTICLE FILTER</text>
<path class="call" d="M820 897h138l27 18h176"/><circle cx="820" cy="897" r="4" fill="#c65d3b"/><circle cx="1182" cy="915" r="17" fill="#c65d3b"/><text x="1182" y="915" class="num">6</text><text x="1148" y="911" class="label" text-anchor="end">CROSS PLATE</text><text x="1148" y="931" class="sub" text-anchor="end">RIGID FILTER SUPPORT</text>
</g>
<!-- footer key -->
<g transform="translate(75 887)"><rect width="360" height="68" rx="8" fill="#f9faf7" stroke="#9aabad"/><circle cx="27" cy="23" r="7" fill="#c65d3b"/><text x="45" y="28" class="sub">CENTERLINE / JOINING AXIS</text><path d="M20 48h22" stroke="#c65d3b" stroke-width="2" marker-end="url(#arrow)"/><text x="52" y="53" class="sub">COMPONENTS SHOWN IN STACK ORDER</text></g>
<text x="1325" y="966" class="sub" text-anchor="end">01 / EXPLODED VIEW</text>
</svg>round 1 of 2
The filter stack is in the right order but drawn under the carafe, which is not how it goes together.
modelopenai/gpt-5.6-soltasksvg-french-press@v2date2026-09-22rounds2 of 8 allowedcost$0.2744thinkingmediumtokens48,689 in, 6,397 out, of which 1,042 reasoningtime1 min 38 sfailurepart-order
All seven partsdecided by looking · Pass if all seven are drawn as separate shapes and each has a label naming it. A part that is only named in a label or a comment, with nothing drawn, fails it.pass
Stack orderdecided by a number, from the filefail
Filter fits the glassdecided by a number, from the filepass
One assembly axisdecided by looking · Pass if one vertical line runs through the middle of every part, and every leader line leaves from the same side. One part pushed off to the side fails it.pass
Labels matchdecided by looking · Pass if following each leader line from its label ends on the part that label names. One label pointing at the wrong part, or at nothing, fails it.pass
There is no post about this one, since only some results need one, so the picture, the source and the scoring are here instead.
run 2 · 1r · $0.1763Right order in one round, but the plates are under 80% of the glass width, and the cross-plate is drawn behind the carafe rim.
run 3 · 1r · $0.2093Right order in one round, but the plates and mesh are barely over half the width of the carafe they have to seal against.same prompt, other modelsall 33 runs on Exploded French press →
Draw an exploded assembly diagram of a French press, as an SVG. Use the standard three-piece plunger filter rather than a two-piece travel press.Frozen at v2. This model got this and nothing else.
The standard three-piece plunger, from the top down: spiral (spring) plate, mesh screen, cross-plate. The cross-plate is the bottom piece, because its threaded stem is what the rod screws into. The spiral plate above the mesh is what presses the mesh edge out against the glass. Checked against the WebstaurantStore anatomy diagram, which is drawn exploded and labelled, and against each part's y coordinate in the SVG rather than its comment. Two-piece travel presses exist and stack differently, which is why v2 of the prompt names the design. How it is scored, and this run's files on GitHub.
