press.svg · 130 lines
<svg xmlns="http://www.w3.org/2000/svg" width="1200" height="900" viewBox="0 0 1200 900">
<defs>
<linearGradient id="bg" x1="0" y1="0" x2="0" y2="1">
<stop offset="0" stop-color="#f7f5ef"/><stop offset="1" stop-color="#ebe7dc"/>
</linearGradient>
<linearGradient id="steel" x1="0" y1="0" x2="1" y2="0">
<stop offset="0" stop-color="#69737a"/><stop offset=".18" stop-color="#e5e8e6"/><stop offset=".42" stop-color="#8f989c"/><stop offset=".68" stop-color="#f4f5f2"/><stop offset="1" stop-color="#687278"/>
</linearGradient>
<linearGradient id="darkSteel" x1="0" y1="0" x2="1" y2="1">
<stop offset="0" stop-color="#475158"/><stop offset=".5" stop-color="#aab0b1"/><stop offset="1" stop-color="#333c42"/>
</linearGradient>
<linearGradient id="glass" x1="0" y1="0" x2="1" y2="0">
<stop offset="0" stop-color="#c7e5e7" stop-opacity=".58"/><stop offset=".18" stop-color="#fff" stop-opacity=".22"/><stop offset=".52" stop-color="#b7dadd" stop-opacity=".12"/><stop offset=".82" stop-color="#fff" stop-opacity=".48"/><stop offset="1" stop-color="#92c5ca" stop-opacity=".52"/>
</linearGradient>
<pattern id="mesh" width="7" height="7" patternUnits="userSpaceOnUse" patternTransform="skewX(-18)">
<path d="M0 0V7M0 0H7" stroke="#657076" stroke-width=".7" opacity=".85"/>
</pattern>
<filter id="shadow" x="-30%" y="-30%" width="160%" height="180%">
<feGaussianBlur in="SourceAlpha" stdDeviation="5"/><feOffset dy="7"/><feComponentTransfer><feFuncA type="linear" slope=".2"/></feComponentTransfer><feMerge><feMergeNode/><feMergeNode in="SourceGraphic"/></feMerge>
</filter>
<marker id="arrow" markerWidth="8" markerHeight="8" refX="7" refY="4" orient="auto"><path d="M0 0L8 4L0 8Z" fill="#9d3f2d"/></marker>
<clipPath id="bodyClip"><path d="M470 645 L486 838 Q600 864 714 838 L730 645Z"/></clipPath>
</defs>
<rect width="1200" height="900" fill="url(#bg)"/>
<path d="M0 116H1200" stroke="#d3cdc0"/><path d="M0 856H1200" stroke="#d3cdc0"/>
<text x="60" y="57" font-family="Arial,sans-serif" font-size="30" font-weight="700" fill="#26343a" letter-spacing="2">FRENCH PRESS</text>
<text x="61" y="87" font-family="Arial,sans-serif" font-size="14" fill="#657177" letter-spacing="3">EXPLODED ASSEMBLY · THREE-PIECE PLUNGER FILTER</text>
<text x="1140" y="67" text-anchor="end" font-family="Arial,sans-serif" font-size="12" fill="#727a7c">ASSEMBLY AXIS</text>
<!-- assembly centerline -->
<path d="M600 124V844" stroke="#9d3f2d" stroke-width="1.5" stroke-dasharray="7 9" opacity=".62" marker-end="url(#arrow)"/>
<!-- knob -->
<g filter="url(#shadow)">
<ellipse cx="600" cy="148" rx="47" ry="15" fill="#202a2e"/>
<path d="M553 148v22c0 10 21 18 47 18s47-8 47-18v-22c0 10-21 18-47 18s-47-8-47-18z" fill="#303b40"/>
<ellipse cx="600" cy="148" rx="47" ry="15" fill="#475258"/>
<ellipse cx="585" cy="144" rx="20" ry="6" fill="#6d777b" opacity=".5"/>
</g>
<!-- lid and rod -->
<g filter="url(#shadow)">
<path d="M472 230v28c0 17 57 31 128 31s128-14 128-31v-28z" fill="url(#steel)" stroke="#37444a" stroke-width="2"/>
<ellipse cx="600" cy="230" rx="128" ry="31" fill="url(#steel)" stroke="#37444a" stroke-width="2"/>
<ellipse cx="600" cy="230" rx="109" ry="23" fill="#758086" opacity=".34"/>
<ellipse cx="600" cy="230" rx="13" ry="6" fill="#303b40"/>
<path d="M720 228l38 8-31 16" fill="url(#steel)" stroke="#37444a" stroke-width="2"/>
</g>
<rect x="595" y="166" width="10" height="275" rx="4" fill="url(#steel)" stroke="#4e5a5f"/>
<path d="M600 297v136" stroke="#fff" stroke-width="2" opacity=".62"/>
<path d="M594 432h12l-2 18h-8z" fill="#555f63"/>
<!-- motion/spacing chevrons -->
<g fill="#9d3f2d" opacity=".75"><path d="M587 317l13 12 13-12v7l-13 12-13-12z"/><path d="M587 352l13 12 13-12v7l-13 12-13-12z"/></g>
<!-- 1 spiral plate -->
<g filter="url(#shadow)">
<ellipse cx="600" cy="478" rx="109" ry="25" fill="#9ba3a5" stroke="#39464b" stroke-width="2"/>
<ellipse cx="600" cy="474" rx="92" ry="19" fill="#d4d7d4" stroke="#566166"/>
<ellipse cx="600" cy="474" rx="19" ry="7" fill="#737d80"/>
<path d="M510 470Q520 448 536 468T563 468T590 468T617 468T644 468T671 468T694 470" fill="none" stroke="#414d52" stroke-width="4"/>
<ellipse cx="600" cy="478" rx="106" ry="23" fill="none" stroke="#4b565a" stroke-width="5" stroke-dasharray="5 3"/>
</g>
<!-- 2 mesh screen -->
<g filter="url(#shadow)">
<ellipse cx="600" cy="548" rx="106" ry="25" fill="url(#mesh)" stroke="#3e4c52" stroke-width="3"/>
<ellipse cx="600" cy="548" rx="12" ry="5" fill="#e3e3dd" stroke="#475359" stroke-width="2"/>
<ellipse cx="600" cy="548" rx="99" ry="21" fill="none" stroke="#738087"/>
</g>
<!-- 3 cross plate -->
<g filter="url(#shadow)">
<ellipse cx="600" cy="618" rx="99" ry="23" fill="#b8bebd" stroke="#39464b" stroke-width="2"/>
<ellipse cx="600" cy="618" rx="86" ry="18" fill="#e0e2df" stroke="#667175"/>
<path d="M518 618h164M600 600v36M541 607l118 22M541 629l118-22" stroke="#525e63" stroke-width="6"/>
<ellipse cx="600" cy="618" rx="15" ry="6" fill="#606b6f" stroke="#354147"/>
<path d="M594 612v12M606 612v12" stroke="#e0e2df" stroke-width="1"/>
</g>
<!-- carafe behind -->
<g filter="url(#shadow)">
<!-- handle -->
<path d="M718 682Q831 665 834 754Q837 829 721 818" fill="none" stroke="#263238" stroke-width="26"/>
<path d="M729 700Q806 691 808 754Q810 801 728 800" fill="none" stroke="#b9c2c1" stroke-width="7" opacity=".65"/>
<!-- glass vessel -->
<path d="M462 652L478 838Q600 870 722 838L738 652Z" fill="url(#glass)" stroke="#53747b" stroke-width="3"/>
<path d="M470 672L484 829Q600 855 716 829L730 672" fill="none" stroke="#fff" stroke-width="3" opacity=".7"/>
<!-- rim -->
<ellipse cx="600" cy="652" rx="138" ry="34" fill="#d9eff0" fill-opacity=".38" stroke="#506d73" stroke-width="3"/>
<ellipse cx="600" cy="652" rx="122" ry="26" fill="#eeeae0" stroke="#6f8589" stroke-width="2"/>
<ellipse cx="600" cy="652" rx="113" ry="21" fill="#b8d6d7" fill-opacity=".28" stroke="#739398"/>
<!-- reflections -->
<path d="M492 697l11 113" stroke="#fff" stroke-width="9" stroke-linecap="round" opacity=".55"/>
<path d="M696 700l-5 52" stroke="#fff" stroke-width="5" stroke-linecap="round" opacity=".4"/>
<!-- base -->
<path d="M478 838Q600 870 722 838" fill="none" stroke="#38565e" stroke-width="6"/>
</g>
<!-- leaders left -->
<g font-family="Arial,sans-serif">
<g><path d="M192 161H536" stroke="#687579"/><circle cx="192" cy="161" r="15" fill="#26343a"/><text x="192" y="166" text-anchor="middle" fill="white" font-size="13" font-weight="700">A</text><text x="221" y="155" fill="#26343a" font-size="16" font-weight="700">KNOB</text><text x="221" y="175" fill="#6b7578" font-size="12">press to plunge</text></g>
<g><path d="M192 242H466" stroke="#687579"/><circle cx="192" cy="242" r="15" fill="#26343a"/><text x="192" y="247" text-anchor="middle" fill="white" font-size="13" font-weight="700">B</text><text x="221" y="236" fill="#26343a" font-size="16" font-weight="700">LID + PLUNGER ROD</text><text x="221" y="256" fill="#6b7578" font-size="12">rod passes through lid</text></g>
<g><path d="M192 657H455" stroke="#687579"/><circle cx="192" cy="657" r="15" fill="#26343a"/><text x="192" y="662" text-anchor="middle" fill="white" font-size="13" font-weight="700">F</text><text x="221" y="651" fill="#26343a" font-size="16" font-weight="700">GLASS CARAFE</text><text x="221" y="671" fill="#6b7578" font-size="12">beaker, rim and handle</text></g>
</g>
<!-- leaders right filter detail -->
<g font-family="Arial,sans-serif">
<text x="930" y="405" fill="#9d3f2d" font-size="12" font-weight="700" letter-spacing="2">STANDARD 3-PIECE FILTER</text>
<path d="M705 478H895" stroke="#687579"/>
<circle cx="915" cy="478" r="16" fill="#9d3f2d"/><text x="915" y="483" text-anchor="middle" fill="white" font-size="13" font-weight="700">1</text>
<text x="946" y="474" fill="#26343a" font-size="16" font-weight="700">SPIRAL PLATE</text><text x="946" y="494" fill="#6b7578" font-size="12">spring edge seals wall</text>
<path d="M708 548H895" stroke="#687579"/>
<circle cx="915" cy="548" r="16" fill="#9d3f2d"/><text x="915" y="553" text-anchor="middle" fill="white" font-size="13" font-weight="700">2</text>
<text x="946" y="544" fill="#26343a" font-size="16" font-weight="700">FINE MESH SCREEN</text><text x="946" y="564" fill="#6b7578" font-size="12">captures coffee grounds</text>
<path d="M702 618H895" stroke="#687579"/>
<circle cx="915" cy="618" r="16" fill="#9d3f2d"/><text x="915" y="623" text-anchor="middle" fill="white" font-size="13" font-weight="700">3</text>
<text x="946" y="614" fill="#26343a" font-size="16" font-weight="700">CROSS PLATE</text><text x="946" y="634" fill="#6b7578" font-size="12">rigid support; threads to rod</text>
</g>
<!-- assembly note -->
<g transform="translate(858 731)">
<rect width="278" height="91" rx="5" fill="#f4f1e9" stroke="#c6bfb1"/>
<text x="18" y="25" font-family="Arial,sans-serif" font-size="11" font-weight="700" fill="#9d3f2d" letter-spacing="1.3">ASSEMBLY ORDER</text>
<text x="18" y="49" font-family="Arial,sans-serif" font-size="13" fill="#354348">Rod → spiral plate → mesh → cross plate</text>
<text x="18" y="70" font-family="Arial,sans-serif" font-size="12" fill="#697477">Tighten cross plate onto threaded rod.</text>
</g>
<text x="61" y="883" font-family="Arial,sans-serif" font-size="11" fill="#777e7d" letter-spacing="1">EXPLODED VIEW — COMPONENT SPACING NOT TO SCALE</text>
</svg>Right order in one round, but the plates are under 80% of the glass width, and the cross-plate is drawn behind the carafe rim.
modelopenai/gpt-5.6-soltasksvg-french-press@v2date2026-09-22rounds1 of 8 allowedcost$0.1763thinkingmediumtokens18,571 in, 4,488 out, of which 472 reasoningtime1 min 2 sfailurephysical-plausibility
All seven partsdecided by looking · Pass if all seven are drawn as separate shapes and each has a label naming it. A part that is only named in a label or a comment, with nothing drawn, fails it.pass
Stack orderdecided by a number, from the filepass
Filter fits the glassdecided by a number, from the filefail
One assembly axisdecided by looking · Pass if one vertical line runs through the middle of every part, and every leader line leaves from the same side. One part pushed off to the side fails it.pass
Labels matchdecided by looking · Pass if following each leader line from its label ends on the part that label names. One label pointing at the wrong part, or at nothing, fails it.pass
There is no post about this one, since only some results need one, so the picture, the source and the scoring are here instead.
run 1 · 2r · $0.2744The filter stack is in the right order but drawn under the carafe, which is not how it goes together.
run 3 · 1r · $0.2093Right order in one round, but the plates and mesh are barely over half the width of the carafe they have to seal against.same prompt, other modelsall 33 runs on Exploded French press →
Draw an exploded assembly diagram of a French press, as an SVG. Use the standard three-piece plunger filter rather than a two-piece travel press.Frozen at v2. This model got this and nothing else.
The standard three-piece plunger, from the top down: spiral (spring) plate, mesh screen, cross-plate. The cross-plate is the bottom piece, because its threaded stem is what the rod screws into. The spiral plate above the mesh is what presses the mesh edge out against the glass. Checked against the WebstaurantStore anatomy diagram, which is drawn exploded and labelled, and against each part's y coordinate in the SVG rather than its comment. Two-piece travel presses exist and stack differently, which is why v2 of the prompt names the design. How it is scored, and this run's files on GitHub.
