<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 900 1320" font-family="Helvetica Neue, Helvetica, Arial, sans-serif">
<defs>
<linearGradient id="steelBand" x1="0" y1="0" x2="1" y2="0">
<stop offset="0" stop-color="#87919a"/>
<stop offset="0.22" stop-color="#d9dfe3"/>
<stop offset="0.5" stop-color="#f0f3f5"/>
<stop offset="0.78" stop-color="#bfc8cf"/>
<stop offset="1" stop-color="#79838c"/>
</linearGradient>
<radialGradient id="discTop" cx="0.42" cy="0.36" r="0.85">
<stop offset="0" stop-color="#f4f7f8"/>
<stop offset="0.6" stop-color="#dde3e7"/>
<stop offset="1" stop-color="#bcc6cd"/>
</radialGradient>
<radialGradient id="knobGrad" cx="0.35" cy="0.3" r="0.9">
<stop offset="0" stop-color="#6d747b"/>
<stop offset="0.55" stop-color="#3a4046"/>
<stop offset="1" stop-color="#20242a"/>
</radialGradient>
<linearGradient id="glassGrad" x1="0" y1="0" x2="1" y2="0">
<stop offset="0" stop-color="#a9c3d3" stop-opacity="0.55"/>
<stop offset="0.18" stop-color="#e8f2f7" stop-opacity="0.35"/>
<stop offset="0.5" stop-color="#ffffff" stop-opacity="0.18"/>
<stop offset="0.82" stop-color="#dceaf1" stop-opacity="0.35"/>
<stop offset="1" stop-color="#93aebf" stop-opacity="0.55"/>
</linearGradient>
<pattern id="mesh" width="7" height="7" patternUnits="userSpaceOnUse">
<path d="M0 0 L7 7 M7 0 L0 7" stroke="#6f7d88" stroke-width="1.1" fill="none"/>
</pattern>
</defs>
<rect width="900" height="1320" fill="#fafbfc"/>
<text x="450" y="46" text-anchor="middle" font-size="30" font-weight="700" letter-spacing="8" fill="#2f3b43">FRENCH PRESS</text>
<text x="450" y="74" text-anchor="middle" font-size="13" letter-spacing="3.5" fill="#8798a4">EXPLODED ASSEMBLY DIAGRAM</text>
<line x1="450" y1="100" x2="450" y2="1298" stroke="#a9b4bc" stroke-width="1.5" stroke-dasharray="7 6"/>
<!-- 1 knob -->
<g>
<rect x="439" y="128" width="22" height="16" rx="3" fill="url(#steelBand)" stroke="#7c868e"/>
<circle cx="450" cy="106" r="27" fill="url(#knobGrad)" stroke="#1c2024"/>
<ellipse cx="441" cy="95" rx="10" ry="7" fill="#ffffff" opacity="0.22"/>
</g>
<!-- 2 plunger rod -->
<g>
<rect x="444" y="144" width="12" height="200" fill="url(#steelBand)" stroke="#7c868e" stroke-width="0.8"/>
<rect x="435" y="344" width="30" height="13" rx="3" fill="#9aa5ad" stroke="#76808a"/>
<path d="M438 348 H462 M438 352 H462" stroke="#66707a" stroke-width="1.2"/>
</g>
<!-- 3 lid -->
<g>
<path d="M295 402 L295 424 A155 24 0 0 0 605 424 L605 402 Z" fill="url(#steelBand)" stroke="#7c868e"/>
<ellipse cx="450" cy="402" rx="155" ry="24" fill="url(#discTop)" stroke="#8b959d" stroke-width="1.5"/>
<ellipse cx="450" cy="402" rx="142" ry="20.5" fill="none" stroke="#c5ced4" stroke-width="1.2"/>
<ellipse cx="450" cy="402" rx="24" ry="7.5" fill="#d8dee3" stroke="#939da5"/>
<ellipse cx="450" cy="402" rx="9" ry="3" fill="#4d565e"/>
</g>
<!-- Standard three-piece filter: spring plate, mesh, cross plate. -->
<!-- 4 upper spring plate: open radial support with a coiled perimeter seal -->
<g>
<g transform="translate(450 500) scale(1 .22)" fill="none" stroke="#a5afb7">
<circle r="132" stroke-width="17"/>
<path d="M-132 0 H132 M-66 -114 L66 114 M66 -114 L-66 114" stroke-width="17"/>
<circle r="23" fill="#dce3e8" stroke="#7c8992" stroke-width="3"/>
</g>
<ellipse cx="450" cy="500" rx="143" ry="32" fill="none" stroke="#6e7d87" stroke-width="9"/>
<ellipse cx="450" cy="500" rx="143" ry="32" fill="none" stroke="#d9e0e5" stroke-width="8" stroke-dasharray="2 4"/>
<ellipse cx="450" cy="500" rx="8" ry="3" fill="#46555e"/>
</g>
<!-- 5 thin woven mesh screen, reinforced edge and central aperture -->
<g>
<ellipse cx="450" cy="596" rx="144" ry="32" fill="#e4ebef" stroke="#85949e" stroke-width="3"/>
<ellipse cx="450" cy="594" rx="143" ry="31" fill="url(#mesh)" stroke="#9caab3" stroke-width="2"/>
<ellipse cx="450" cy="594" rx="13" ry="4.5" fill="#dce3e8" stroke="#8998a2"/>
<ellipse cx="450" cy="594" rx="8" ry="2.5" fill="#46555e"/>
</g>
<!-- 6 lower cross plate: open ring and cruciform support, threaded hub -->
<g>
<g transform="translate(450 682) scale(1 .22)" fill="none" stroke="#818e98">
<circle r="134" stroke-width="16"/>
<path d="M-134 0 H134 M0 -134 V134" stroke-width="23"/>
</g>
<g transform="translate(450 678) scale(1 .22)" fill="none" stroke="#c1ccd4">
<circle r="134" stroke-width="16"/>
<path d="M-134 0 H134 M0 -134 V134" stroke-width="23"/>
</g>
<path d="M435 670 V684 Q450 690 465 684 V670" fill="url(#steelBand)" stroke="#7c8992"/>
<ellipse cx="450" cy="670" rx="15" ry="5" fill="#dce3e8" stroke="#8998a2"/>
<ellipse cx="450" cy="670" rx="7" ry="2.5" fill="#46555e"/>
</g>
<g font-size="12.5" fill="#788b98">
<text x="656" y="514">Coiled perimeter seal</text>
<text x="254" y="622" text-anchor="end">Fine stainless-steel weave</text>
<text x="656" y="698">Threaded lower support</text>
</g>
<!-- 7 glass carafe -->
<g>
<path d="M300 758 L300 1032 A150 22 0 0 0 600 1032 L600 758 A150 22 0 0 0 300 758 Z" fill="url(#glassGrad)" stroke="#8fa6b5" stroke-width="2"/>
<path d="M300 1032 A150 22 0 0 0 600 1032 Z" fill="#89a5b7" opacity="0.22"/>
<rect x="326" y="780" width="24" height="235" rx="12" fill="#ffffff" opacity="0.4"/>
<rect x="549" y="786" width="10" height="220" rx="5" fill="#ffffff" opacity="0.3"/>
<ellipse cx="450" cy="758" rx="150" ry="22" fill="#ffffff" opacity="0.15" stroke="#8fa6b5" stroke-width="2"/>
<path d="M314 741 L262 720 Q300 731 297 757 Z" fill="#bfd3e0" stroke="#8fa6b5" stroke-width="1.5" stroke-linejoin="round"/>
<path d="M304 744 L272 727" stroke="#e2edf3" stroke-width="1.6" fill="none" stroke-linecap="round"/>
</g>
<!-- 8 frame with handle -->
<g>
<ellipse cx="450" cy="1098" rx="168" ry="30" fill="none" stroke="url(#steelBand)" stroke-width="11"/>
<ellipse cx="450" cy="1180" rx="168" ry="30" fill="none" stroke="url(#steelBand)" stroke-width="11"/>
<g stroke="#a7b1b9" stroke-width="8" stroke-linecap="round">
<path d="M330 1119 V1201 M570 1119 V1201"/>
<path d="M386 1077 V1159 M514 1077 V1159" opacity="0.45"/>
</g>
<path d="M618 1108 C700 1094 714 1172 618 1170" fill="none" stroke="#96a1a9" stroke-width="12" stroke-linecap="round"/>
</g>
<!-- 9 base -->
<g>
<path d="M278 1248 L278 1268 A172 22 0 0 0 622 1268 L622 1248 Z" fill="url(#steelBand)" stroke="#7c868e"/>
<ellipse cx="450" cy="1248" rx="172" ry="22" fill="url(#discTop)" stroke="#8b959d" stroke-width="1.4"/>
<ellipse cx="450" cy="1248" rx="146" ry="17" fill="none" stroke="#bcc5cc" stroke-width="1.3"/>
</g>
<!-- labels -->
<g stroke="#90a4ae" stroke-width="1.5" fill="none">
<path d="M424 96 L302 84"/>
<path d="M458 244 L620 234"/>
<path d="M338 397 L218 386"/>
<path d="M528 494 L648 488"/>
<path d="M314 591 L262 596"/>
<path d="M528 676 L648 672"/>
<path d="M301 900 L192 900"/>
<path d="M300 1194 L266 1146"/>
<path d="M334 1252 L212 1258"/>
</g>
<g fill="#78909c">
<circle cx="424" cy="96" r="3.2"/>
<circle cx="458" cy="244" r="3.2"/>
<circle cx="338" cy="397" r="3.2"/>
<circle cx="528" cy="494" r="3.2"/>
<circle cx="314" cy="591" r="3.2"/>
<circle cx="528" cy="676" r="3.2"/>
<circle cx="301" cy="900" r="3.2"/>
<circle cx="300" cy="1194" r="3.2"/>
<circle cx="334" cy="1252" r="3.2"/>
</g>
<g font-size="20" font-weight="600" fill="#37474f">
<text x="294" y="90" text-anchor="end">1 · Knob</text>
<text x="628" y="240">2 · Plunger rod</text>
<text x="210" y="392" text-anchor="end">3 · Lid</text>
<text x="656" y="494">4 · Spring plate</text>
<text x="254" y="602" text-anchor="end">5 · Mesh screen</text>
<text x="656" y="678">6 · Cross plate</text>
<text x="184" y="906" text-anchor="end">7 · Glass carafe</text>
<text x="258" y="1146" text-anchor="end">8 · Frame/handle</text>
<text x="204" y="1264" text-anchor="end">9 · Base</text>
</g>
<text x="450" y="1310" text-anchor="middle" font-size="12.5" letter-spacing="1.5" fill="#9fb0ba">STANDARD THREE-PIECE PLUNGER FILTER · PARTS 4 – 6</text>
</svg>round 1 of 5
Seven parts, the stack the right way up, and labels on both sides of one axis.
modelunbiased/paretotasksvg-french-press@v2date2026-09-22rounds5 of 8 allowedcost$0.3558thinkingmediumtokens125,141 in, 32,364 out, of which 0 reasoningtime4 min 54 s
All seven partsdecided by looking · Pass if all seven are drawn as separate shapes and each has a label naming it. A part that is only named in a label or a comment, with nothing drawn, fails it.pass
Stack orderdecided by a number, from the filepass
Filter fits the glassdecided by a number, from the filepass
One assembly axisdecided by looking · Pass if one vertical line runs through the middle of every part, and every leader line leaves from the same side. One part pushed off to the side fails it.pass
Labels matchdecided by looking · Pass if following each leader line from its label ends on the part that label names. One label pointing at the wrong part, or at nothing, fails it.pass
There is no post about this one, since only some results need one, so the picture, the source and the scoring are here instead.
run 1 · 4r · $0.4670
run 2 · 4r · $0.3719The same result in one round fewer, with a handle drawn on the carafe.
run 2 · 2r · $0.2169
run 3 · 2r · $0.4528Cross-plate on top of the mesh again, and plates that are the wrong diameter for the glass. Cut off by provider timeouts after round 2.same prompt, other modelsall 33 runs on Exploded French press →
Draw an exploded assembly diagram of a French press, as an SVG. Use the standard three-piece plunger filter rather than a two-piece travel press.Frozen at v2. This model got this and nothing else.
The standard three-piece plunger, from the top down: spiral (spring) plate, mesh screen, cross-plate. The cross-plate is the bottom piece, because its threaded stem is what the rod screws into. The spiral plate above the mesh is what presses the mesh edge out against the glass. Checked against the WebstaurantStore anatomy diagram, which is drawn exploded and labelled, and against each part's y coordinate in the SVG rather than its comment. Two-piece travel presses exist and stack differently, which is why v2 of the prompt names the design. How it is scored, and this run's files on GitHub.
